Model / 型號
|
FZ-KP2
|
FZ-KP2T
|
|
Emitting element/發光源
|
Red LED 680 nm
|
Red LED 680 nm
|
|
Operating voltage/工作電壓
|
DC12~24V ± 10%
|
|
Current Consumption/消耗電流
|
35mA Max.
|
40mA Max.
|
|
Load current / 負載電流
|
100mA Max at DC 24V in, Residual voltage :1V Max
|
|
Output Type / 輸出模式
|
NPN N.O. / N.C. PNP N.O./N.C.
|
|
Protection circuit / 保護電路
|
Reversed polarity protection, over-current protection, surge absorber
|
|
Response time/反應時間
|
0.5 ms
|
1 ms
|
|
Indicators/指示燈
|
Output indicator ：Red LED, Power indicator：Green LED
|
|
Sensitivity adjusrment/靈敏度功能
|
4 turns trimmer
|
|
Timer function / 定時器功能
|
–
|
One shot / Off-delay / 0~7 sec.
|
|
Protection degree/防水等級
|
IP64
|
|
Material/外觀材質
|
ABS
|
|
Wiring method / 出線方式
|
Pre-wired Ø4.2 x 2M / 4-wires
|
|
Weight /重量
|
Approx.85 g
|
